OMNITRONIC LH-110 A/B-Y signal switcher

Main page » Audio » Audio processors » Little Helper » 10355110

Product No.:10355110
Print product data sheet:
This Product was added to our catalogue on Wednesday, 23. March 2011.

Seen cheaper ?

Tell us where you have seen this article cheaper, and we will try to beat this price! » Price inquiry

Signal switcher for studio and stage applications

For switching stage equipment in both directions
Routes the mixed input signal either to output A or B/ or to both outputs
In reverse direction, the LH-110 switches between A and B and sends the signal to the inputs
2 LEDs indicate which of the jacks A, B or both are connected to the inputs
Ideal e.g. for musicians for switching one instrument between two amplifiers or in reverse for switching between two instruments in to one amplifier
Inputs and outputs via unbalanced 6.3 mm jacks
Operation with 9 V battery

Power supply:	1 standard 9 V battery
Power consumption:	2 W
T.H.D.:	0.01 %
S/N ratio:	>80 dB
Dimensions:	95 x 73 x 40 mm
Weight:	340 g
